18 Inch REGULAR Green 5 Digits 7 Segment Gas Station LED Price Sign

Transform your gas station’s pricing display with our premium 18-inch LED price sign featuring bright green digits. This professional-grade sign showcases 5 digits in a clear 7-segment format, making prices easily visible from far distances, day or night. Perfect for gas stations, fuel centers, and convenience stores, this regular-sized display ensures your fuel prices are prominently displayed to passing motorists. The energy-efficient LED technology provides exceptional brightness while keeping operating costs low. Built with weather-resistant materials and advanced electronics, this sign delivers reliable performance in all conditions. Easy to install and program, it allows quick price updates to keep your business competitive. The crisp green digits offer excellent contrast and readability, helping you attract more customers and comply with pricing display regulations.

Introduction

LED Chips parameter
Color	Brightness	Wave Length	Current	Operating Voltage	Viewing angel	LED Chips size	Color temperature	Luminous flux
RED	4000mcd	620-630	60MA	1.9-2.4V	60°/120° /180°	10*20Mil	620-650K	2LM
GREEN	10000mcd	515-525		3.0-3.4V			515-525K	3LM
BLUE	8000mcd	515-525		2.5-3.0V			460-470K	3LM
YELLOW	3500mcd	585-590		1.9-2.2V			588-595K	1.5LM
WHITE	12000mcd	0		3.0-3.4V			6000-7000K	5LM

SERIES PARAMETERS
Item	Technical Parameters
Color:	Red, Amber, Green, Blue, White
Digit Height:	6″, 8″, 10″, 12″, 15″, 18″, 20″, 22″, 24″, 32″, 64″, 72″
Digit Design:	7 segments modules are sealed with glue,reach IP67 waterproof grade,with dust shade that make leds work normally all the time.
Brightness Control:	Auto dimming by brightness sensor
Display Dimming:	Over 8 levels of automatic intensity adjustment
Viewing Angle:	Horizontal:60°-120°,Vertical: 60°-120° or customized
Service Access:	Front or rear open
Master/slave:	Single sided or double sided, master/slaves available
Cabinet Material:	Iron cabinet or aluminum alloy frame
Waterproof Level:	IP53 with aluminum alloy frame, IP65 with iron cabinet
Led Driving Mode:	Constant current
Power Input:	110/220V AC,50-60HZ
PC Communication:	RS232/485;LAN(TCP/IP) with cables or wireless,customer can choose
Communication Distance:	Max.15 meters for RS232, 1200 meters for RS485
Remote Control Type:	RF remote control (Normal 6 buttons or LCD remote controller)
Continuous Working Time:	Unlimited
Lifetime of Leds:	100,000 hours
Installation Method:	Hanging,mounting or per custom design
Working Temperature:	-40°C~75°C
Display Format:	8.88, 8.888,8.888, 8.889/10, 88.88, 88.888 etc.

Detailed Images

Features：

*led highlight number,easy catch people’s eys on high way

* material of the cabinet can choose iron,aluminum ,simple box

* IP 65 waterproof case

* It can use as gas price sign, countdown, time, tempreture, scoreboard, speed limit and so on.

* Easy to instal,which can assemble any formats you want. 8.8. , 8.8.8., 8.8.8.8. , 8.8.8.8.8. etc.

Control Way

Control Way: RF remote Control

Control Distance: 30m -100m

Brightness Grade: 8 grades by automatic adjustment

Production line

Packing

Installation Instructions

FAQ

Question 1: Led digits sign can not work well, some led modules can not be lighting.

Answer :
A.Please check the connecting cables of drive card whether it is loose or not,and connect them again.
B.LED module is broken, please replace the new module to the led sign.
C.Please set the correct quantity of the numbers.For example: 88.88, 8.889/10 is 4 numbers.(Single sided or double sided are the same).
D.Please check drive card’s 2pin ports,and connect to other 2pin ports or change led number.

Question 2: All the led digits are not lighting.Some led signs are controlled together, but only the sign which has control (main) card can work, the other signs can not work.

Answer :
A. Please use the multi-meter to check power supply whether it is on or off.
B. And please connect the power supply cables again.
C. Please check power supply whether it is 12V.

Question 3: Some led signs are controlled together, but only the sign which has control (main) card can work normally, the other signs can not work well.

Answer :
A. Please check the cables of control card and connect them again.
B. Please use the RF remote controller to set the numbers again.
C. Please check the connecting cable of control card and drive card.
D. Please check IN and OUT port.
E. Please connect them again.
F. Please check control card’s signal light is on.
